The bright, modern building offers 174,000 square feet of indoor space as well as an outdoor pool, two sand volleyball courts and a basketball court. Inside, visitors find courts for basketball, volleyball, racquetball and more, 8-lane pool, tracks for walking, jogging and running, fitness studios, climbing wall, tennis complex with hitting wall, weight training and conditioning areas, multipurpose rooms, and fully equipped locker rooms.
With a budget of $38.7 million, the Dr. Betty L. Siegel Center replaces an earlier 55,000-square-foot facility that opened in 1967. One of the highest priorities in building the new facility was sustainability, both in the materials used and the energy performance, all with the goal of minimizing its carbon footprint. The project architect and builder selected materials that would best contribute to that goal.
One of the key components in the wall construction is the use of Kingspan GreenGuard Type IV 25 PSI XPS Insulation Board
from Kingspan Insulation. The two-story building features masonry framing with a brick exterior, and the Kingspan GreenGuard XPS Insulation Board provides the ideal exterior insulation performance for this cavity wall application.
Extruded polystyrene (XPS) provides superior moisture resistance, and because it does not absorb moisture, it retains its insulating properties over time. With an R-Value of 5.0 per inch of thickness, the board increases energy efficiency while offering the advantage of being lightweight, easy to handle, and easy to cut with a knife. In this application at KSU, the board is two inches thick for an R-10 value, which exceeds the code requirement for the area.
The Dr. Betty L. Siegel Center is constructed with a concrete block base covered by a fluid-applied membrane. Brick ties from the block extend out to the brick, and the Kingspan GreenGuard XPS Insulation Board is friction fit between the brick ties with an adhesive on the back that helps strengthen the bond between the board and the fluid layer. Two inches of dead space between the insulation board and the brick allows for drainage and ventilation that enhances the performance and further eliminates moisture issues.
Construction of the dramatic new facility began in late 2013 and took about 18 months. Since its official opening and dedication, the Dr. Betty L. Siegel Student Recreation and Activities Center has become one of the key buildings on campus and is performing as planned. Every exterior brick wall on the building features the Kingspan GreenGuard Type IV 25 PSI XPS Insulation Board underneath, ensuring that it will deliver many years of enjoyment for students and faculty at KSU.
