QuadCore Louvre Wall Panel is a secret-fix wall panel with distinctive fin profile. This panel can be installed both horizontally and vertically.

  • Standard Lengths: 1.8m - 14.5m
  • Core Thickness: 45mm - 150mm
  • Vertical or Horizontal
  • Can achieve a U-value of 0.12 (W/m²K)

Technical & Downloads

Available Lengths

Standard lengths: 1.8 - 14.5m

Longer lengths (non-standard): 14.5 – 19.2m

Shorter lengths (non-standard): Below 1.8m

Note: Additional costs and transport restrictions may apply for non-standard lengths. All lengths may change for export (outside of the UK & Ireland).

Dimensions, Weight and Thermal Performance

Core Thickness (mm) 45 54 60 70 74 80 88 100 120 140 150
Overall Thickness (mm) 63 72 78 88 92 98 106 118 138 158 168
U-value (W/m².K)

0.43 0.35 0.31 0.27 0.25 0.23 0.21 0.18 0.15 0.13 0.12
Weight (kg/m²) 10.8 11.2 11.4 11.8 11.9 12.1 12.5 12.9 13.7 14.4 14.8

The QuadCore insulation used in QuadCore Louvre Wall Panel has a Thermal Conductivity (λ) of 0.018W/m.K

QuadCore Louvre Wall Panel has a Thermal Transmittance (U-Value), calculated using the method required by the Building Regulations Part L2 (England & Wales), Building Standards Section 6 (Scotland), Part L (Republic of Ireland) and Part F2 (Northern Ireland).

Insulation Core

QuadCore Louvre Wall Panel is manufactured with a HCFC, CFC and HFC free QuadCore insulation core.

Certification and Testing

Reaction to Fire

QuadCore Louvre Wall Panel is classified B-s1,d0, when tested on the internal face of the product, according to the European Reaction to Fire classification system (Euroclasses) EN 13501-1:2018 under the certified name AWP Product Family when using the following internal liners:

CLEANsafe 15, CLEANsafe 25, CLEANsafe 55, CLEANsafe120, AQUAsafe 55

Please contact Kingspan Tech-eXchange for information relating to the external face.

Insurer Approvals

QuadCore Louvre Wall Panels are tested to:

LPS 1181 Part 1: Issue 1.2 Requirements and tests for built-up cladding and sandwich panel systems for use as the external envelope of buildings certified to:

LPS 1181-1 Grade EXT-B under the certified name Benchmark Louvre DW for thicknesses 45 – 150mm



Insurer approvals are large scale testing regimes that provide objective third-party testing, which is underpinned by quarterly, bi-annual and annual factory surveillance audits (depending on the region) to verify compliance. Insurer approvals are subject to panel thickness, cover width, orientation, method of assembly, steel coating and manufacturing facility. Please contact Kingspan Tech-eXchange for further information.

Environmental

Kingspan Insulated Panels produced in the UK are certified to BES 6001 (Framework Standard for the Responsible Sourcing of Construction Products) ‘Very Good’.

All Kingspan Insulated Panels manufacturing facilities across the UK and Ireland are 100% Net Zero Energy. In addition, facilities located in Kingscourt, Holywell and Sherburn generate renewable energy onsite which contributes to that sites energy mix.

Kingspan Insulated Panels procure steel that is made from 15 – 25% recycled content. Kingspan insulated panels directly contribute to BREEAM® / LEED® credits.

Air Leakage

An air leakage rate of 3m³/hr/m² at 50Pa or less can be achieved when using Kingspan insulated roof and wall panels.

For information on detailing required to achieve lower air leakage rates please contact Kingspan Tech-eXchange.

Acoustic

Sound Reduction Index (SRI)


Hz* 63 125 250 500 1000 2000 4000 8000
SRI 20 18 20 24 20 29 39 47


* Frequency

QuadCore Curved Wall Panels have a single figure weighted sound reduction Rw = 25dB. Results are based on panels of similar profile and core material.

Materials - Substrate

Metallic protected steel to BS EN 10346:2015.

Please contact Kingspan Tech-eXchange for information on other substrates.

Coatings - External Weather Sheet

Kingspan XL Forté: Consists of a multi-layer organic coating, embossed with a traditional leather-grain finish.

Kingspan Spectrum: Consists of a coated semigloss finish with slight granular effect.

For Reaction to Fire performance of external weather sheets please contact Kingspan Tech-eXchange.

Coatings - Internal Liner Sheet

Kingspan CLEANsafe 15: The coating has been developed for use as the internal lining of insulated panels. Standard colour is “bright white” with an easily cleaned surface.

Kingspan CLEANsafe 120: The coating has been developed for use as the internal lining of insulated panels where a high level of cleanliness and hygiene is required, and the panels are to be cleaned down on a regular basis.

Kingspan AQUAsafe 55: The coating has been developed for use as the internal lining of insulated panels for swimming pools and other high humidity internal environments.

For reaction to fire performance of panels with above internal liners please see certification and testing section.

Product Tolerance

Cut to Length: ±5mm
Cover Width: ±2mm
Thickness (Core ≤ 100mm): ±2mm
Thickness (Core > 100mm): ±2%
End Square: ±3mm

Seals

Factory applied side joint seals. All side joints have a factory applied seal fitted into the groove to automatically seal the joint between panels.

Quality and Durability

QuadCore Louvre Wall Panel is manufactured from the highest quality materials, using state of the art production equipment to rigorous quality control standards, complying with BS EN ISO 9001 standard, ensuring long term reliability and service life. The panels are also being manufactured under Environmental Management System Certification BS EN ISO 14001, Energy Management System Certification BS EN ISO 50001 and Occupational Health and Safety Certification BS EN ISO 45001. QuadCore Louvre Wall Panel is CE marked to BS EN 14509: 2013.

Warranty

QuadCore® Assured Panel Warranty

25 years insurance backed thermal performance
25 years insurance backed fire performance
25 years structural performance
25 years environmental performance
Up to 40 years coating performance

QuadCore® Assured System Warranty

25 years insurance backed thermal performance
25 years insurance backed fire performance
25 years structural performance
25 years environmental performance
Up to 40 years coating performance
25 years warranty on system accessories*

*Please contact Kingspan Tech-eXchange or refer to the ‘Quadcore Assured’ brochure for a list of accessories covered by Kingspan.

Packing

QuadCore Louvre Wall Panels are stacked weather sheet to liner sheet. The top and sides are protected by either cardboard or polystyrene and spiral wrap stretch polyfilm. The number of panels in a pack will vary depending on thickness.


Core Thickness (mm) 45 54 60 70 74 80 88 100 120 140 150
No. of panels in Pack  16 15 15 13 12 12 10 10 7 7 6


Note: Applies to UK pack sizes. Please contact Kingspan Tech-eXchange for export information.

Sea Freight

Fully timber crated packs are available on projects requiring delivery by sea freight shipping, at additional costs. Alternatively, steel containers can be used. Special loading charges apply.

Delivery

All deliveries (unless indicated otherwise) are by road transport to project site. Off-loading is the responsibility of the client.

Site Installation Procedure

Site assembly instructions and construction details are available from Kingspan Tech-eXchange.
